BIM & Level of detail

bim

BIM & Level of detail

31 March 2024

BIM can be implemented at different levels of detail (LOD) to cater to various purposes throughout the construction project.


The LOD framework encompasses six levels, ranging from LOD 100 to LOD 500, each representing different degrees of detail and development in the BIM model.


When implementing BIM, the choice of LOD depends on the project's phase and objectives. “Adopting the appropriate LOD at each stage of the project can streamline communication, reduce errors, and enhance collaboration among project stakeholders”.


One critical aspect in the field of construction is Building Information Modeling (BIM), which can be implemented at different levels of detail (LOD) to cater to various purposes throughout a construction project. The LOD framework encompasses six levels, ranging from LOD 100 to LOD 500, each representing different degrees of detail and development in the BIM model. Let's delve into each level to gain a better understanding.


At LOD 100, BIM focuses on the conceptual design, capturing the basic massing and shape of the building. This level is particularly useful for initial design and feasibility studies. Moving on to LOD 200, BIM becomes more detailed, providing approximate sizes, shapes, and locations of major building components. LOD 200 is employed during design development stages.


Detailed geometric information and relationships are imperative at LOD 300. This level offers precise details and includes specific product and material information. Construction documentation and clash detection purposes best utilize LOD 300. Building upon LOD 300, LOD 350 adds further detail, offering exact quantities, sizes, shapes, and locations of building components. It becomes suitable for generating construction drawings and schedules.


As we progress to LOD 400, BIM becomes apt for construction and fabrication. It provides comprehensive information on assembly, maintenance, and operation of building components. LOD 400 is primarily employed during on-site construction and coordination. Finally, at LOD 500, the BIM model represents the actual installed and constructed elements, incorporating as-built information such as dimensions, specifications, and maintenance records. This level finds its purpose in facility management and maintenance.


When implementing BIM, the choice of LOD depends on the project's phase and objectives. Lower LODs, such as LOD 100 and 200, are suitable for conceptualization and design during the early stages. On the other hand, higher LODs, ranging from 300 to 500, become indispensable for detailed construction and facility management. Adopting the appropriate LOD at each stage of the project can streamline communication, reduce errors, and enhance collaboration among project stakeholders.
